| Place of Origin: | China |
| Brand Name: | JWSY |
| Model Number: | JWS-YL102 |
▋Technical Specifications
| Power Supply Voltage | DC12V/2A |
| Maximum Power Consumption | ≤12W |
| Communication Interface | RS485/9600bps, WG26/WG34 |
| Electrical Interface | Vehicle detector input, gate opening signal relay output |
| Card Reading Speed | <0.2s/≤60Km/h |
| Card Reading Interval | <0.5s |
| Card Reading Distance | 3-25m (adjustable) |
| Card Reading Area | 60° fan-shaped area |
| Working Mode | Active card reading, ground sensor triggered card reading |
| Working Temperature/Humidity | -30°C~+75C/10%~90% |
| Installation Method | Universal adjustment/vertical pole mounting |
| Dimension/Weight | 24.727.65.8cm/4.5 Kg |
| Protection Grade | IP65 |
▋Product Features
Industrial-grade design with 32-bit ARM chip and Cortex-M3 core, featuring powerful functions and stable performance.
60° infrared directional scanning and identification, dual-band complementation, two-way communication.
Multi-group device code verification, no interference between adjacent lanes.
Adjustable signal strength, supporting both indoor and outdoor working modes.
Supports encrypted usage.
Full nixie tube display for intuitive clarity and simple operation.
Double relay output with configurable delayed barrier drop.
Wireless installation, no wiring required.
No computer needed in the guard booth.
Blacklist distribution via USB flash drive, supporting more than 150 blacklist entries.
In and out records extraction via USB flash drive, with over 15,000 in and out records stored in the system.
Supports voice broadcast and display screen connection.
