Recessed Automatic Swing Gate IP68 Ground Buried Installation

Name: Recessed Automatic Swing Gate IP68 Ground Buried Installation
Brand: Shenzhen Jieweishi Technology Co., Ltd.
SKU: W‑MJ105
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	JWSY
Model Number:	W‑MJ105

Detail Information

Place of Origin:

China

Brand Name:

JWSY

Model Number:

W‑MJ105

Device Name:

Recessed Automatic Swing Gate

Set Size:

320x110x70(mm)

Control Cabinet Size:

160x116x50(mm)

The Max Door Weight:

200kg

Installation Method:

Ground Buried

Open-close Time:

6-12S

Highlight:

High Light

Highlight:

Recessed Automatic Swing Gate

Automatic Swing Gate IP68

Automatic Swing Gate Ground Buried

Trading Information

Minimum Order Quantity:

10 units

Packaging Details:

Carton packaging

Delivery Time:

10 Work days

Payment Terms:

Payment before delivery

Supply Ability:

10000 units

Product Description

▋Recessed Automatic Swing Gate

The unit utilizes the output shaft of the unit to drive the rotating arm to achieve automatic operation

The operation of the door body can be applied both indoors and outdoors.

▋Technical Specifications

The max door weight	200kg
The max door width	1200mm
The max torque	165Nm
Setweight	5.5kg
Installation method	Ground buried
Noise	<60dB
Electric lock output	DC12V normally open / normally close contactor
Open-close time	6-12S
Start range	86--175°
Power supply	AC220V+10% 50.60Hz
Rated power	55w
Standby time	<2W
Working temperature	-20'C to 55°C
Protection grade	IP68 (Only limit at motor)
Set size	320x110x70(mm)
Control cabinet size	160x116x50(mm)

▋Operating instruction and safety notices

● Please read the installation debugging instruction carefully before use this product

and follow the related safety standards.

● Need confirm the set and controller no damage appearance before installation.

● This product should connect the reliable grounding wire and constructed by the

professional electric engineering staffs.

● The power supply should be cut off status before wiring, otherwise, it’s dangerous

at electric shock!

● Confirm whether voltage and frequency are in accordance with the equipment

requirements before connect power supply, check whether wiring terminal are firm,

whether wiring electric circuit and position are correct.

● The controller elements can’t be touched by hands after connected power,

otherwise, it’s dangerous at electric shock, should cut off the power supply first when

installing and maintaining, wear the gloves well then process operation.

● The manufacturer will not duty for any liabilities for the result which caused by

incorrect installation, operation and non-safety use environment.
